Rotel DT-6000 Diamond Series DAC Transport

Rotel’s Diamond Series DT-6000 DAC Transport celebrates 60-Years of performance, passion, and value synonymous with the brands Japanese heritage.

An 8-channel ESS Saber ES9028PRO DAC dedicates 4 channels each to stereo outputs rendering unprecedented details with an ultra-low noise floor and immersive sound stage.

Dedicated power supplies feed critical circuits utilizing an in-house manufactured toroidal transformer with isolation techniques lowering residual noise and distortion.

The PC-USB input supports up to 32-bit/384kHz including MQA (24-bit/384kHz) and DSD (4X). Optical and Coaxial inputs are also included supporting 24-bit/192kHz streams.

The tray loading CD utilizes Rotel’s 30-years of multi-award winning CD player design experience extracting every nuance and detail from CD collections both large and small.

FEATURES

• ESS premium 32-bit/384kHz 8-Channel Digital to Analog Converter
• Smooth tray loading CD mechanism
• 12 volt trigger input
• Fully balanced differential XLR outputs
• Supports MQA and MQA Studio
• Certified Roon Tested

TECHNICAL SPECS

• Total Harmonic Distortion + Noise
• Coaxial/Optical Input < 0.0007%
• CD/PC-USB Input < 0.0012%
• Intermodulation Distortion: < 0.0012%
• Frequency Response (0±0.5 dB)
• 20 Hz – 20k Hz, +0, -0.15dB
• 10 Hz – 70k Hz, +0, -3dB
• Channel Balance: ± 0.5 dB
• Channel Separation: > 115 dB @ 10k Hz
• Signal to Noise Ratio: > 115 dB
• Power Requirements: USA 120 V, 60 Hz
• Power Consumption: 25 watts
• Standby Power Consumption: < 0.5 watts
• Dimensions (W x H x D): 17 x 4 x 12 3/5 in
• Weight (net): 17.88 lbs
