The Aethos stereo amplifier is housed in a brand new, custom-designed case. Employing four 160 W 16 Amp output transistors per channel, this delivers 156 W per channel into 6 Ω. The Aethos is a dual-mono design using a custom wound toroidal transformer and regulated supplies for the sensitive amplification and driver stages. The pre-amplifier stage uses class-A discrete circuitry throughout. The Aethos is a no-compromise product with one goal, to deliver your music as faithfully as possible.

FEATURES

156 W per channel into 6 Ω (125 W per channel into 8 Ω)
Dual mono design
5 Line inputs
Headphone socket
Remote control
Direct input
Record out
Pre-amp out
Lifetime warranty against manufacture defects

TECHNICAL SPECS

Power outputs at rated 230/115 V supply voltage:
125 W RMS both channels driven into the rated load of 8 Ω
156 W RMS both channels driven into 6 Ω
Headphone output:
No load 12.5 V
32 Ω 2.7 V
54 Ω 4 V
300 Ω 9 V
Source impedance 109 Ω
Record output level (with rated input levels) 219 mV
Record output impedance 560 Ω
Pre-amp output level (with rated input levels) 840 mV
Pre-amp output impedance 100 Ω
Input 1-5 and record input sensitivity 224 mV @ 17 kΩ
Maximum input level 11.5 V (record output amplifier overload point)
Direct input sensitivity 840 mV @ 50 kΩ
Power amplifier gain 31.6 dB
Frequency response @ 100 W into 8 Ω:
Line input 1-5 and record 10 Hz (-0.8 dB point) to 30 kHz (-0.5 dB point)
Direct input 10 Hz (-0.8 dB point) to 50 kHz (-0.5 dB point)
THD+Noise @ 100 W into 8 Ω:
Direct input (Power amplifier only) Typically 0.007% @ 1 kHz (measurement bandwidth
22 Hz to 30 kHz)
Line input Typically 0.007% @ 1 kHz (measurement bandwidth
22 Hz to 30 kHz)
Power consumption Maxiumum output: 415 W @ 230 V / 220 V / 115 V / 100 V into the
rated load of 124 W RMS into 8 Ω
Fuse ratings T5 AL 250 V – 230 V / 50 Hz and 220 V / 60 Hz
T8 AL 250 V – 115 V / 60 Hz and 100 V 50/60 Hz
Dimensions W 433 mm x H 95 mm x D 360 mm (including speaker terminals)
Weight 17.5 kg
