NAD C 568 Single-Disc CD Player

NAD’s C 568 CD player was designed as a direct upgrade to the award-winning NAD C 565 BEE and includes all the features you need for an easy and joyous CD-listening experience. Complete with the new NAD CD-8 remote control, the C 568 delivers a high level performance worthy of your music library.

FEATURES

• Plays CDs, CD-Rs & CD-RWs, and MP3 & WMA CDs
• 196kHz/24-bit digital-to-analog converter
• Power supply has separate power regulators for analog and digital sections
• Vacuum fluorescent display with CD text
• Play, pause, and skip functions via a front-panel rotary knob
• Front-panel USB input for playing music from a thumb drive, MP3 player, or hard drive
• Optical and coaxial digital audio outputs
• Stereo RCA outputs
• IR input
• What’s in the Box:
• CD player
• 6.5′ AC power cord
• Remote control (CD 9) and batteries
• 3′ RCA stereo cable

TECHNICAL SPECS

• Output Level Analog: 2.2 ± 0.1 V
• Frequency Response:  ±0.3 dB (ref. 0 dB 20 Hz-1 kHz) ±0.5 dB (ref. 0 dB 5 kHz-20 kHz)
• Total Harmonic Distortion: <0.01% (ref. 1 kHz, Audio LPF)
• Signal / Noise Ratio: 118 dB (ref. 1 kHz, A-weighted LPF Stop, Pause)
• Channel Balance: ±0.5 dB (ref. 0dB 1kHz)
• Dynamic Range: 95 dB
• Channel Separation: >90 dB
• De-emphasis: -3.73 to -5.33 dB (ref. 0dB 1 kHz, 5 kHz) -8.04 to -10.04 dB (ref. 0dB 1 kHz, 16 kHz)
• Linearity: ±0.01 dB (ref. 0dB 1 kHz at -3 dB) ±0.02 dB (ref. 0dB 1 kHz at -6 dB) ±0.02 dB (ref. 0dB 1 kHz at -10 dB) ±0.05 dB (ref. 0dB 1 kHz at -20 dB) ±0.15 dB (ref. 0dB 1 kHz at -60 dB)
• Standby Power: <0.5w USB
• Output Level: 2.2 ± 0.2 V
• Frequency Response: ±1 dB (ref. 0 dB 20 Hz – 16 kHz)
• Total Harmonic Distortion: <0.03% (ref. 0 dB 1 kHz, Audio LPF)
• Unit Dimensions: 80 mm h x 435 mm w x 306 mm d
• Net weight: 10.8 lbs
