It Starts with the Disc
Whether playing SACDs, CDs, or other data discs containing music, it’s vital that any player retrieves the information as accurately as possible: unlike a computer reading a disc for ripping, there’s no time for repeated re-scans when playing music – it happens in real time, so the disc transport needs to get things right first time.

CDs, SACDs and Beyond
The SA-10 goes so much further than just disc playback: it’s also a fully-functional digital-to-analog converter for music stored on a home computer, as well as having conventional digital inputs for existing source components. Those conventional inputs – optical and coaxial – can handle your music files up to 192kHz/24bit.

More than just a DAC
The SA-10 takes things further – just as it features an all-new disc transport mechanism, so the digital to analog conversion has also been subject to a radical rethink, taking full advantage of the 1-bit conversion technology found in past flagship Marantz players, and incorporating brand-new filtering and up-conversion to take advantage of this simple, but elegant solution.

FEATURES

Hear all your music: From SACDs to DSD files, enjoy all of your music without limits.
Pure Marantz Sound: HDAM technology combined with optimized circuit design layout and carefully selected components, provides exceptional sound quality and performance.
Sound Master Tuned: Engineered and extensively tuned by a team drawing on more than 35 years of Marantz CD and SACD design knowledge.
Upscale Listening: Innovative Marantz Musical Mastering “MMM-Stream” up-sampling to DSD and filtering

TECHNICAL SPECS

CD Compatibility: CD / CD-R/RW / SA-CD / WMA / MP3 / AAC
Yes / Yes / Yes / Yes / Yes / Yes
CD-Text / SA-CD Text / ID3 Tag / WMA Meta Tag / AAC Meta data
No / Yes / Yes / Yes / Yes
Data Disc Compatibility: DSD / WAV / ALAC <=5.6 / 192 / 96
HDAM version: HDAM+HDAM SA2
Power Transformer: Toroidal / El Yes / No
High Grade Audio Components: Yes
Customised Components: Yes
Symmetric circuit layout: Yes
Copper Plated Chassis: Yes
Extra metal plate for chassis strengthing: Yes
Program Play (CD / SA-CD): Yes / Yes
Repeat: Yes
Random Play: Yes
Start Sound Mode for SA-CD: Yes
Balanced Out: Yes
Digital Optical In / Out: Yes / Yes
Digital Coaxial In / Out: Yes / Yes
Sample Rate digital In: 192 kHz / 24-bit
Digital Filter: DSP (Marantz)
Low Pass Filter stage: HDAM x 2
Output Buffer: HDAM SA2
Frequency response: 2 Hz – 20 kHz
Dynamic Range: 98 dB
Signal to Noise Ratio: 104 dB
Total Harmonic Distortion: 0.00%
Channel separation: 100 dB
Maximum Dimensions (W x D x H) in mm: 440 x 419 x 127(17.32 x 16.49 x 5 inches)
Weight in kg: 18.4 (40.57 lbs)
