Reference 10001A mono subwoofer amplifier delivers a blistering 1,000-Watts RMS using Class D amplifier topology to ensure cool running and minimal current draw. Speaker-level inputs allow this amplifier to integrate into almost any system, even one using your car’s factory radio — and Infinity includes RCA-to-speaker wire adapters so you’ll make the right connections. You can use the low-pass filter and variable bass boost to maximize the performance of your subwoofer and enclosure, while a phase switch ensures that the bass will blend well with your full-range speakers.

FEATURES

Compact size
High and low level input
Variable crossover and bass boost
Low noise and distortion
Input Level Control
Full on-board protection
Phase Switch
RBC wired remote
Strappable for up to 2,000 watts of power at 4 ohms
Class D amp technology
Turn-on mode

TECHNICAL SPECS

Mono subwoofer car amplifier
600 watts RMS x 1 at 4 ohms
(1000 watts RMS x 1 at 2 ohms)
Class D amp technology
Frequency response: 10–320Hz
Variable low-pass filter (32–320Hz, 12dB/octave)
Variable bass boost (0–12dB at 45Hz)
Phase switch (0, 180 degrees)
Wired remote level control included
Preamp inputs and outputs
Speaker-level inputs (speaker wire-to-RCA
adapters included)
4-gauge power and ground leads recommended — wiring and hardware not included with amplifier Fuse rating: 35A x 3
W x H x D = 320mm x 55.5mm x 180mm
W x H x D = 12-5/8″ x 2-3/16″ x 7-1/8″
