Chord TToby 100w Stereo Power Amplifier

TToby complements Chord’s desktop DAC / headphone amplifier, Hugo TT, and shares the same compact form factor as its stablemate. The combination of Hugo TT and TToby provides a high-quality Hi-Fi system, with desktop dimensions and a space-saving footprint. Despite its size, TToby sets new standards for small amplifiers and takes full advantage of Chord Electronics’ proprietary amplification technology and design know-how.

The addition of TToby enables owners of Hugo TT to fully exploit the device as a digital preamp, effortlessly driving a wide variety of loudspeakers, large or small, in addition to Hugo TT’s headphone prowess. TToby is a 100-watt design, featuring both an unbalanced and balanced input, to take advantage of Hugo TT’s XLR output.

TToby features two of Chord’s famous high-frequency power supplies and benefits from forced air-cooling through the aluminum casework by means of a sonically closed anechoic miniature multi-speed quadruple-fan plenum chamber, enabling the external design to be free of sharp heatsinks and, therefore, carry a stunning aesthetic. The Hugo TT / TToby combination offers both class-leading DAC and amplification technology via headphones and loudspeakers, giving complete flexibility within the demands of busy households.

FEATURES

• 100w into 4Ω
• >-103dB signal to noise ratio
• Class AB sliding bias
• HF switch mode power supply
• Chord MOSFET construction
• Fully balanced circuitry
• Fan cooled
• Stereo balanced XLR inputs
• Stereo unbalanced RCA inputs
• Solid aluminum chassis

TECHNICAL SPECS

• Output Power: 100w RMS per channel @ 0.016% distortion into 4Ω
• Frequency Range: 5 Hz – 100 kHz +/- 0.5 dB
• Signal to Noise Ratio: Better than -103 dB
• Channel Separation: Better than 95 dB
• Input Impedance: 100 kΩ unbalanced / balanced
• Input Capacitance: <32 pf
• Output Inductance: 2.6μH
• Slew Rate: 70 v per μS 1 kHz, 20 v square wave
• Gain: 30 dB
• Stability: Unconditional
• Dimensions: 9.25″w (235 mm) x 8.86″d (225 mm) x 2.17″h (55 mm)
• Weight: 3.75 k
